Place of Origin: | CHINA |
Brand Name: | MILE |
Certification: | ISO, CE, SGS |
Model Number: | MILE-PVC |
Minimum Order Quantity: | 100 square meters |
---|---|
Price: | FOB QINGDAO,1.00-5.00/square meter |
Packaging Details: | 20m ,25m /roll with draft bag |
Delivery Time: | 7 days after order confirmation |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
Supply Ability: | 50000 square meters |
Features: | Anti-UV | Type: | Swimming Pool Liners |
---|---|---|---|
Material: | PVC | Color: | Blue Or Customized. |
Thickness: | 1.2mm,1.5 Mm,2.0mm | Width: | 1.0-3.0m |
Roll Length: | 20m, 25m Or Customized | Application: | Swimming Pool |
Product Description:
PVC Pool liner is one kind of Polyvinyl chloride liner, reinforced with polyester mesh, mixing additives, stabilizers, etc. The product is corrosion-resistant and chlorine-resistant. It has excellent size stability and lower thermal expansion coefficient, so it has strong adaptability to the external environment
All kinds of single colors and different pattern available
Type |
swimming pool liner
|
Application |
Swimming pool
|
Thickness |
0.75mm, 0.9mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm
|
Width |
1.0m-3.0m
|
Length |
20m, 25m or customized
|
Color |
Blue or customized
|
Packing |
Kraft Bag
|
Specification:
No. | Items |
Technical Data
|
|
1 | Weight per square meter (kg/m2) | 1.9(±10%) | |
2 | Density (g/m3) | 1.23(±10%) | |
3 | Low Temperature Flexibility | No cracking | |
4 | Flame Resistance | B1 | |
5 | Impermeability | No leaking | |
6 | Tensile Strength | MD(N/cm) | ≥180 |
TD(N/cm) | ≥180 | ||
7 | Breaking Elongation | MD(%) | ≥120 |
TD(%) | ≥120 | ||
8 | Tear Strength | MD(%) | ≥75 |
TD(%) | ≥75 | ||
9 | Heat treatment dimensional change rate | MD(%) | ≤0.2 |
TD(%) | ≤0.2 |
Stored membranes in dry and cool condition,
Prevent from sunlight, rain,
low temperature and chemicals
Operation introduction:
1. Pool bottom preparation:
Pool bottom kinds: concrete, steel construction, mosaic tile
Note: if it is concrete, it must be cement matte surface. Make sure it is flat, dry and no sand
2.Clear the ready pool bottom well
3.Mixed the two compensate glue well, then put it on the pool bottom and wall evenly and fully. Lay the PVC liner on it.
Cut freely as the size, use welding gun to weld liner overlapping. With cork mood make the PVC liner more flat.
Note: the overlapping size at least 5cm
4.Use liquid PVC do the side joint secondly to make sure good adhesive performance.
5.Please do other details handle, like water inlet/ outlet, light, etc according to your design.
