    Product Details:

    Place of Origin: CHINA
    Brand Name: MILE
    Certification: ISO,CE
    Model Number: MILE-PHS

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000 square meters
    Price: FOB QINGDAO, USD5.0/ square meter
    Packaging Details: Plastic packing
    Delivery Time: 7 -10days after order confirmation
    Payment Terms: L/C, D/A, D/P, T/T, Western Union
    Supply Ability: 100,000 square meters per month
    Contact Now
    Detailed Product Description
    Material: HDPE Color: White
    Thickness: 1.0mm, 1.2mm, 1.5mm Width: 1m
    Roll Length: 20 Meters Usge: Underground Waterproof
    Adhesion: Self-adhesive Warranty: 5 Years
    Certification: ISO, CE

    Product Description:

    Its base material is HDPE, both sides are covered with self-adhesive layer, and faced with removable silicone-coated film as isolation layer. For special construction conditions, geotextile can be compound on polymer layer, it can bond with concrete layer tightly. After Membrane bonding with concrete, water can be blocked between membrane and concrete, which can improve the reliability.

    Pre-applied Waterproofing Membrane is composed of HDPE sheet, one special pressure sensitive adhesive, and artificial granule covering layer.
     HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls

    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls

    Membrane sizes

     thickness width roll length
    1.2mm,1.5mm,2.0mm 1.0  meter  20 meters


    Technical date sheet:

    No. Items JL 1 JL 2
    1 Tensile Strength Tension, N/50mm ≥500 ≥800
    Breaking Elongation, % ≥400 -
    2 Tear Strength, N ≥400 ≥200
    3 Impermeability, 0.3Mpa, 30 minutes No leaking No leaking
    4 Low Temperature Flexibility -25℃ -35℃
    5 Thermal Stability Appearance No Distortion
    Size, % ≤2.0
    6 Hot Air Aging (70℃, 168 hours) Tensile Retention ≥90%
    Breaking Elongation Retention ≥80%
    7 Peeling Strength with post casting concrete, N/mm No treatment ≥2.0
    Cement, Sands surface ≥1.5
    Ultraviolet Radiation Aging surface ≥1.5
    Hot Aging surface ≥1.5

    Product Effect :
    1.The membrane can be fully bond to poured concrete.
    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls
    2.The membrane can be fully bond to poured concrete.
    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls

    Features:
    1)Good weather fastness and dimensional stability.

    2) Combined concrete and waterproofing membrane closely.

    3) Higher tensile strength and better extensibility under normal construction conditions.

    4) Easy installation, solid joint, and no environmental pollution.

    5) Good rooting penetration resistance.

    How to apply Mile pre-applied waterproof membrane:

    Step 1, Clean the basement, make sure no sharp stones.

    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls
    Step 2, Unfold the membrane on the basement.

    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls
    Step 3, Overlap width should up to 8cm to ensure enough adhesive strength.

    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls

    Step 4, MILED-150 (Reinforced double side tape) is helpful for overlap.

    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls

    Step 5, Some Details Treatment - inside and outside corners.

    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls
    Step 6, Some Details Treatment - pile head and anchor rod.
    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls

    Step 7, Some Details Treatment - pinhole fix (use MILET-150 sandy tape).

    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls

    Our service:
    1, One stop service from design of waterproofing system,materials providing to technology support.

    2, It is free for design and technology support of waterproofing system.

    3,supplying most accessories of waterproofing system,such as,self adhesieve tape,sealants,prefabriated parts.


    Storage and Transportation:
    1) Package in plastic bag.
    2) stored in well-ventilated place
    3) Avoid direct sunshine, rain, keep ventilated.
    4) be put horizontally no more than five-level



    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls

    HDPE Self-adhesive Waterproof Membrane Pre-applied with Glue with Release Film for Retaining Walls
