| Place of Origin: | CHINA |
| Brand Name: | MILE |
| Certification: | ISO, CE, SGS |
| Model Number: | MILE-HDPE |
| Minimum Order Quantity: | 100 square meters |
|---|---|
| Price: | FOB Qingdao USD3.00-5.00 per square meters |
| Packaging Details: | Plastic Bag |
| Delivery Time: | 7-10 days after order confirmation |
| Payment Terms: | L/C, D/A, D/P, Western Union |
| Supply Ability: | 100,000 square meters per month |
| Material: | HDPE | Thickness: | 1.2MM/1.5MM Or Customized |
|---|---|---|---|
| Width: | 1M,2M | Length: | 20M Or Customized |
| Color: | White | Sample: | Free Samples Available |
| Certification: | ISO, CE |
Product Description:
Pre-applied Waterproofing Membrane is composed of HDPE sheet, one special pressure sensitive adhesive, and artificial granule covering layer.
|
Total thickness (mm) |
HDPE thickness (mm) |
Width (m) |
Length (m) |
Remarks |
| 1.5 | 1.2 | 1.0 / 2.0 | 20 | Granule thickness not included |
Technical Data Sheet:
| No. | Items | JL 1 | JL 2 | ||
| 1 | Tensile Strength | Tension, N/50mm | ≥500 | ≥800 | |
| Breaking Elongation, % | ≥400 | - | |||
| 2 | Tear Strength, N | ≥400 | ≥200 | ||
| 3 | Impermeability, 0.3Mpa, 30 minutes | No leaking | No leaking | ||
| 4 | Low Temperature Flexibility | -25℃ | -35℃ | ||
| 5 | Thermal Stability | Appearance | No Distortion | ||
| Size, % | ≤2.0 | ||||
| 6 | Hot Air Aging (70℃, 168 hours) | Tensile Retention | ≥90% | ||
| Breaking Elongation Retention | ≥80% | ||||
| 7 | Peeling Strength with post casting concrete, N/mm | No treatment | ≥2.0 | ||
| Cement, Sands surface | ≥1.5 | ||||
| Ultraviolet Radiation Aging surface | ≥1.5 | ||||
| Hot Aging surface | ≥1.5 | ||||
Product Features:
1)The membrane can be fully bond to poured concrete.
2) Elongation. 600% elongation property.
3) fully bond to poured concrete, to prevent lateral migration of water
4)fully bond to the building, not effected by stratum settlement and deformation
5)easy to operation
Where to apply MILE-HDPE:
Advantages for MILE-HDPE:
How to apply MILE-HDPE:
Step 1, Clean the basement,
make sure no sharp stones Step 2, Unfold the membrane on the basement
Step 3, Overlap width should up to 8cm to ensure enough adhesive strength
Step 4(Reinforced double side tape) is helpful for overlap.
Step 5, Some Details Treatment - inside and outside corners.
Step 6, Some Details Treatment - pile head and anchor rod
Step 7, Some Details Treatment - pinhole fix
Certification:
Our service:
1, One stop service from design of waterproofing system,materials providing to technology support.
2, It is free for design and technology support of waterproofing system.
3,supplying most accessories of waterproofing system,such as,self adhesieve tape,sealants,prefabriated parts.
Storage and Transportation:
1) Package in plastic bag.
2) stored in well-ventilated place
3) Avoid direct sunshine, rain, keep ventilated.
4) be put horizontally no more than five-level
